Gearbox Housing: Ruggedised Die-cast Aluminium
Worm Gear Material: Bronze, steel or plastic
Lubrication: Grease lubricated & sealed for life
Bearing Type: High quality ball bearings
Insulation Class: Class F (Optional: Class B)
Brush Type: Integral or removable
Worm Wheel Material: Delrin, bronze
Gear Ratio: 25:1, 30:1, 60:1, 75:1
Call us for More Information

Gearbox Housing: Ruggedised Die-cast Aluminium
Worm Gear Material: Bronze, steel or plastic
Lubrication: Grease lubricated & sealed for life
Bearing Type: High quality ball bearings
Insulation Class: Class F (Optional: Class B)
Brush Type: Integral or removable
Worm Wheel Material: Delrin, bronze
Gear Ratio: 12:5:1, 25:1, 30:1, 50:1
Call us for More Information

Gearbox Housing: Ruggedised Die-cast Aluminium
Worm Gear Material: Bronze, steel or plastic
Lubrication: Grease lubricated & sealed for life
Bearing Type: High quality ball bearings
Insulation Class: Class F (Optional: Class B)
Brush Type: Integral or removable
Rated Voltage: 24 VDC
Rated Speed: 550 ±10% rpm
Rated Power: 560, 600 W
Gear Ratio: 10:1
Motor Torque: 1.2 Nm
Motor Speed: 5500 ±10% rpm
Duty Cycle: 2 to 3 seconds on,2 to 5 minutes off
Call us for More Information

Gearbox Housing: Ruggedised Die-cast Aluminium
Worm Gear Material: Bronze, steel or plastic
Lubrication: Grease lubricated & sealed for life
Bearing Type: High quality ball bearings
Insulation Class: Class F (Optional: Class B)
Brush Type: Integral or removable
Worm Wheel Material: Derlin, Bronze
Gear Ratio: 12:5:1, 25:1, 30:1, 50:1
Brake Type: ERB, MRB
Output Shaft: Customized
Call us for More Information

Protection Class: IP50
Duty Cycle: S1 (100%)
Rated Voltage: 24 V
Rated Current: 4.9 A
Input Power: 117.6 W
No Load Current: 0.4 A
Rated Torque: 0.27 Nm
Rated Speed: 3300 ±10% rpm
Rated Output Power: 93.3 W
Friction Torque: 2 Ncm
Efficiency: 80%
Max. Torque: 1.3 ±10% Nm
Max. Current: 23 A
No Load Speed: 3650 ±10% rpm
Max. Power: 245 W
Gearbox Ratio: 710:5:1
Gearbox Rated Torque: 120 Nm
Gearbox Max. Torque: 180 Nm
Call us for More Information

Protection Class: IP50
Duty Cycle: S1 (100%)
Rated Voltage: 24 V
Rated Current: 5.5 A
Input Power: 132 W
No Load Current: 1 A
Rated Torque: 0.82 Nm
Rated Speed: 1025 ±10% rpm
Rated Output Power: 88 W
Friction Torque: 2 Ncm
Efficiency: 72%
Max. Torque: 1.9 ±10% Nm
Max. Current: 15 A
No Load Speed: 1300 ±10% rpm
Max. Power: 250 W
Gearbox Ratio: 225:1
Gearbox Rated Torque: 115 Nm
Gearbox Max. Torque: 226 Nm
Call us for More Information

Protection Class: IP50
Duty Cycle: S1 (100%)
Rated Voltage: 24 V
Rated Current: 5.5 A
Input Power: 132 W
No Load Current: 1.2 A
Rated Torque: 0.86 Nm
Rated Speed: 1055 ±10% rpm
Rated Output Power: 88 W
Friction Torque: 2 Ncm
Efficiency: 72%
Max. Torque: 1.9 ±10% Nm
Max. Current: 15 A
No Load Speed: 1300 ±10% rpm
Max. Power: 275 W
Gearbox Ratio: 422:1
Gearbox Rated Torque: 200 Nm
Gearbox Max. Torque: 300 Nm
Call us for More Information

Protection Class: IP50
Duty Cycle: S1 (100%)
Rated Voltage: 24 V
Rated Current: 12.5 A
Input Power: 300 W
No Load Current: 1.7 A
Rated Torque: 0.72 Nm
Rated Speed: 3040 ±10% rpm
Rated Output Power: 229 W
Friction Torque: 2 Ncm
Efficiency: 75%
Max. Torque: 1.9 ±10% Nm
Max. Current: 30 A
No Load Speed: 3500 ±10% rpm
Max. Power: 275 W
Gearbox Ratio: 76:1
Gearbox Rated Torque: 40 Nm
Gearbox Max. Torque: 60 Nm
Call us for More Information
