Rated Voltage: 220 V
Rated Power: 50 & 100 W
Rated Torque: 0.16 & 0.32 Nm
Rated Speed: 3000 rpm
Maximum Torque: 0.48, 0.96 N.m
Rated Current: 0.7 & 1.4 A
Maximum Current: 0.265 A
Torque Constant: 0.265 Nm/A
Rotor Inertia: 0.029, 0.052 Kg*cm2
Back E.M.F: 22 V/Krpm
Protection Class: IP64
Call us for More Information

Rated Voltage: 220 V
Rated Power: 200 & 400 W
Rated Torque: 0.637 & 1.27 Nm
Rated Speed: 3000 rpm
Maximum Torque: 1.91, 3.9 N.m
Rated Current: 1.4 & 2.8 A
Maximum Current: 4.2, 8.4 A
Torque Constant: 0.5 Nm/A
Rotor Inertia: 0.32, 0.51 Kg*cm2
Back E.M.F: 30 V/Krpm
Protection Class: IP64
Call us for More Information

Rated Voltage: 220 V
Rated Power: 400, 740, 1000 W
Rated Torque: 1.3, 2.4, 3.2 Nm
Rated Speed: 3000 rpm
Maximum Torque: 3.9, 7.2, 9.6 N.m
Rated Current: 2.2, 3.9, 6.2 A
Maximum Current: 6.6, 10.8, 18.6 A
Torque Constant: 0.65 Nm/A
Rotor Inertia: 1.15, 1.36, 1.9 Kg*cm2
Back E.M.F: 39 V/Krpm
Protection Class: IP64
Call us for More Information

Rated Voltage: 220V
Rated Power: 750, 730, 1000 W
Rated Torque: 2.4, 3.5, 4 Nm
Rated Speed: 3000, 2000, 2500 rpm
Max Speed: 1300, 2500, 2700 rpm
Maximum Torque: 7.1, 10.5, 12 N.m
Rated Current: 7.9, 15.7, 18 A
Maximum Current: 15.8, 31.4, 36 A
Torque Constant: 1.11, 1.27, 2.53 Nm/A
Rotor Inertia: 1.82, 2.63, 2.97 Kg*cm2
Back E.M.F: 50, 60, 67 V/Krpm
Protection Class: IP64
Call us for More Information

Rated Voltage: 220 V
Rated Power: 600, 1200, 1800 W
Rated Torque: 2, 4, 6 Nm
Rated Speed: 3000 rpm
Maximum Torque: 6, 12, 18 N.m
Rated Current: 2.5, 5, 6 A
Maximum Current: 7.5, 15, 18 A
Torque Constant: 0.91 Nm/A
Rotor Inertia: 3.1, 5.4, 6.3 Kg*cm2
Back E.M.F: 55 V/Krpm
Protection Class: IP64
Call us for More Information

Rated Voltage: 220 V
Rated Power: 1000, 2000, 2600, 3800 W
Rated Torque: 4, 5, 7.7, 10, 15 Nm
Rated Speed: 2000, 2500 rpm
Maximum Torque: 12, 15, 22, 30, 45 N.m
Rated Current: 4, 4.2, 7.5, 10, 13.5 A
Maximum Current: 12, 17.7, 30, 40.5 A
Torque Constant: 1, 1.03, 1.19, 1.58 Nm/A
Rotor Inertia: 10.5, 12, 15.3, 23.4, 29.1 Kg*cm2
Back E.M.F: 67, 72, 79 V/Krpm
Protection Class: IP64
Call us for More Information

Rated Voltage: 220 VDC/VAC
Rated Power: 2.1 W
Rated Torque: 20 Nm
Rated Speed: 1000 rpm
Maximum Torque: 40 N.m
Max Speed: 1300 rpm
Rated Current: 7.9 A
Maximum Current: 15.8 A
Torque Constant: 2.53 Nm/A
Rotor Inertia: 35 Kg*cm2
Back E.M.F: 168 V/Krpm
Protection Class: IP64
Call us for More Information

Rated Voltage: 220 V
Rated Power: 200 & 400 W
Rated Current: 1.6 & 3.1 A
Rated Speed: 3000 rpm
Max Speed: 6000 rpm
Rated Torque: 0.64 & 1.27 Nm
Torque Constant: 0.43 & 0.45 Nm/A
Protection Class: IP64
Call us for More Information

Rated Voltage: 220 V
Rated Power: 750 & 1000 W
Rated Current: 4.0 & 5.5 A
Rated Speed: 3000 rpm
Max Speed: 5000 rpm
Rated Torque: 2.37 & 3.18 Nm
Torque Constant: 0.6, 0.58 Nm/A
Protection Class: IP64
Call Us for More Information

Rated Voltage: 220 V
Rated Power: 850, 1300, 1800 W
Rated Current: 5.0, 7.9. 10.1 A
Rated Speed: 1500 rpm
Max Speed: 2000 rpm
Rated Torque: 5.39, 8.28, 11.5 Nm
Torque Constant: 1.08, 1.05, 1.14 Nm/A
Protection Class: IP64
Call Us for More Information

Low Inertia
Peak torque up to 300% of rated torque
Various models (0.2kw~5kw, with brake, ect.)
Run at speed of up to 4500~5000r/min
Mounted 20 bits incremental / absolute encoder, optional mounted resolver
Call Us for More Information

Medium Inertia
Peak torque up to 300% of rated torque
Various models (0.5kw~1.0kw, with brake, ect.)
Mounted with 17/20 bits serial encoder
Call Us for More Information

To drive the feed shaft of various machinery
1.0 kW ~ 5.0 kW with brakes
Mounted with 17/20 bits serial encoder
IP65
Call Us for More Information

To drive the feed shaft of various machinery
1.0 kW ~ 4.0 kW with brakes
Mounted with 17/20 bits serial encoder
IP65
Call Us for More Information

Power supply voltage: 400V
To drive the feed shaft of various machinery
7.5 kW ~ 22 kW with brakes
Mounted with 17 bits serial encoder
Temperature sensor
Call Us for More Information

Low speed, large torque
Low inertia
Peak torque up to 4 times of rated torque
Cool off options for nature, wind & water
Equiped with resolver
High resolution, 17 bits serial encoder (optional)
